WoodLine SLAT

SLATTED WALL & CEILING SYSTEM

WoodLine Slat is a traditional linear wall and ceiling system that incorporates various blade sizes and spacing. WoodLine Slat is available in 1’ wide by 8’ long sections, with arrangements of three to eight blades per section. Sections are installed using an attachment clip suspended from a heavy duty 15/16” T-grid, and work with both backer and dowel assemblies. Available in genuine wood veneer or laminate. Various acoustical materials can be utilized to garner different acoustical results.

Note: 12-14 week lead time. Minimum of 1,500 SF or larger required to quote. Quick Ship option avaliable with limited size/veneers. No Minimum to quote.

Quick Ship Program

Features
• Linear Wall and Ceiling Blade System
• Assembly: Black Hardwood Backers or Dowels in Fixed Aluminum or Flexible PVC
• Face & Rear Balancing Veneers
• Custom Sizes Available

Standard Dimensions
• Section Size: 1’ W x 8’ L
• Blade Heights: 2” | 3” | 4”
• Blade Widths:
• 6-8 blades: 0.625”
• 5 blades: 0.75”
• 4 blades: 1”
• 3 blades: 1.25”

Installation
• Ceiling: Attachment Clip to Standard T-grid System
• Wall: Wood Screw into Hardwood Backer

Finishes
• Wood Veneer or Laminate on MDF Core
• Natural Clear Lacquer (Veneer Only)

Fire Rating
• Class A fire rating per ASTM E-84
• CARB2

Acoustics
NRC Rating up to 0.90
